DX Kit for Air Handling Applications UTY-VDGX / UTP-VX90A × 2
![UTP-VX30-90AT [EEV unit] and UTY-VDGX [Control unit]](/shared/eu/img-0000-ventilation-uty-vdgx-utp-vx90a-2-01.png "UTP-VX30-90AT [EEV unit] and UTY-VDGX [Control unit]")
Features
- Multiple temperature sensors optimally control an air handling unit and a fan coil unit.
- Supports a wide range of capacity classes
- A variety of control options that meet application requirements
Specifications
| Connectable Capacity Class | 40.0 kW | 50.0 kW | |
|---|---|---|---|
| Capacity | Cooling | 40.0 kW | 50.4 kW |
| Heating | 45.0 kW | 56.5 kW | |
Scroll
| Control Unit | UTY-VDGX | |
|---|---|---|
| Power Source | Phase | Single phase |
| Voltage | 230 V | |
| Frequency | 50 Hz | |
| Net Dimensions | Height | 400 mm |
| Width | 400 mm | |
| Depth | 120 mm | |
Scroll
| EEV Unit | UTP-VX90A × 2 | |
|---|---|---|
| Connection Pipe Diameter (Liquid) | Ø12.7 mm | |
| Net Dimensions | Height | 160 mm |
| Width | 220 mm | |
| Depth | 90 mm | |
Scroll
- Note:
- Specifications are subject to the following conditions:
- Cooling:
- Indoor temperature of 27°C DB/19°C WB; outdoor temperature of 35°C DB/24°C WB
- Heating:
- Indoor temperature of 20°C DB/(15°C WB); outdoor temperature of 7°C DB/6°C WB
- Pipe length:
- 7.5 m
- Voltage:
- 230 V
Dimensions
Control Unit : UTY-VDGX
EEV Unit : UTP-VX90A × 2
