ARXA036GLEH
11.2 kW
12.5 kW
Specifications
| Power Source | Phase | Single phase | |
|---|---|---|---|
| Voltage | 230 V | ||
| Frequency | 50 Hz | ||
| Capacity | Cooling | 11.2 kW | |
| Heating | 12.5 kW | ||
| Input Power | 194 W | ||
| Airflow Rate | Cooling | High | 1840 m³/h |
| Medium High | 1750 m³/h | ||
| Middle | 1660 m³/h | ||
| Low High | 1600 m³/h | ||
| Low | 1530 m³/h | ||
| Quiet | 1470 m³/h | ||
| Heating | High | 1840 m³/h | |
| Medium High | 1750 m³/h | ||
| Middle | 1660 m³/h | ||
| Low High | 1600 m³/h | ||
| Low | 1530 m³/h | ||
| Quiet | 1470 m³/h | ||
| Static Pressure Range | 0 to 150 Pa | ||
| Standard Static Pressure | 50 Pa | ||
| Sound Pressure Level*2 | Cooling | High | 37 dB(A) |
| Medium High | 36 dB(A) | ||
| Middle | 35 dB(A) | ||
| Low High | 35 dB(A) | ||
| Low | 34 dB(A) | ||
| Quiet | 33 dB(A) | ||
| Heating | High | 37 dB(A) | |
| Medium High | 36 dB(A) | ||
| Middle | 35 dB(A) | ||
| Low High | 35 dB(A) | ||
| Low | 34 dB(A) | ||
| Quiet | 33 dB(A) | ||
| Net Dimensions | Height | 270 mm | |
| Width | 1135 mm | ||
| Depth | 700 mm | ||
| Net Weight | 40.0 kg | ||
| Connection Pipe Diameter | Liquid (Flare) | φ9.52 mm | |
| Gas (Flare) | φ15.88 mm | ||
| Drain Hose Diameter | φ25(I.D.), φ32(O.D.) mm | ||
| EV Kit (optional) | EV Kit (optional) | ||
Scroll
Dimensions
Indoor Unit : ARXA036GLEH
