CX Series
Indoor Units :
ASSH18/24/30/36CMTA
ASSH36CXTD
Models
| 220-240V Single-Phase | |
|---|---|
| ASSH18CXTDZ | |
| ASSH24CXTDZ | |
| ASSH30CXTAZ | |
| ASSH36CXTDZ | |
| 380-415V 3-Phase | |
|---|---|
| ASSH36CXTAZ | |
Outdoor Units :
AOSH18CXTD
AOSH24CXTD
AOSH30CXTA
AOSH36CXTA
AOSH36CXTD
Specifications
Features
6 Speed control
6-Speed fan control with added Powerful Cooling mode is provided.
Airflow 38*% up than current model (high mode)
- *
- 36 class
- *
- One touch powerful cooling mode: Continuous operation for 30 minutes at maximum air volume
Powerful cooling
Higher cooling capacity is achieved at the ambient temperature of 52°C condition.
Powerful airflow
Optimized airflow design guarantees long reach cooling up to 25 m. (30 / 36 class).
Inverter technology
Fast cooling
Inverter models cool faster than non-inverter models.
R32 Refrigerant
R32 refrigerant is highly environmentally friendly for the reduction of the global warming potential than another refrigerant.
Refrigerant Cycle Monitor (Option)
Wired Remote Controller (Touch Panel) will support to display some sensor values for maintenance and service support.
- *
- Wired remote controller (UTY-RNRGZ6) is required.
